D151 Домашний Wi-Fi Стандарты и протоколы
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
IEEE 802.3, IEEE 802.3u
ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5
Интерфейс
RJ11 × 1
Power Jack × 1
10/100Mbps LAN × 3
10/100Mbps WAN/LAN × 1
Антенны
5dBi External Omni directional × 1
Кнопки
Reset(RST) × 1
WPS × 1
WLAN On/Off × 1
Power On/Off × 1
Адаптер питания
Input: 100 - 240V 50/60Hz
Output: 9V0.6A
Габариты
157.8 × 105.2 × 29.4mm
LED-индикация
PWR, INTERNET,WPS, WLAN, 4/iTV, LAN3, LAN2, 1/WAN, DSL
Беспроводная скорость
150Mbps
Рабочая частота
2.4GHz
Connection Type
<20dBm(EIRP)
Особенности
Wireless switch enable/disable
SSID Broadcast enable/disable
Country Options
Channel: Auto, 1-13
Bandwidth: Auto, 20MHz, 40MHz
Client List
WDS
Безопасность беспроводной сети
Wireless MAC Filtering
Support 64/128 bit WEP
WPA-PSK/WPA2-PSK
WPS
3G/4G Backup
PPPoE, PPPoA,IPoA, MER, Bridge
Managed By Controller
Wireless Modem Router, Wireless Router
Расширенные функции
PVC/VLAN Configuration
MAC Clone
DSL Settings
Interface Grouping
QoS
Parental Control
IPTV
DHCP
DHCP Server
Client List
Address Reservation
Виртуальный сервер
Port Forwarding
Port Triggering
DMZ
UPnP
Безопасность
IP Filter
MAC Filtering
IPv6
Support 6RD & DS-Lite, IPv6 and IPv4 dual stack
Управление
LAN IP Setting
Backup & Update & Restore to factory default
System Logs
SNMP Agent
TR-069 Client
Internet Time
Access Control
Update Software via web, TFTP & FTP
Diagnostics
Другое
DDNS, IGMP Multicast, VLAN, 802.1Q, Routing
Температура
Operating Temperature: 0℃ ~ 45℃
Storage Temperature: -40ºC~70ºC
Влажность
Operating Humidity: 10% ~ 90%RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing
Настройки по умолчанию
IP Address: 192.168.1.1
Login Username：admin Login Password: admin
Сертификация
CE、FCC、RoHS
Комплект поставки
150Mbps Wireless N ADSL2 Modem Router × 1
Quick Installation Guide x 1
Power Adapter x 1
Ethernet cable (RJ45) x 1
Telephone cable ( RJ11) × 2
Splitter x 1
