Межсетевой экран Fortinet FortiGate-7060E-8-DC 8U 6-slot chassis with 2x FPM-7620E Processor Modules, 2x FIM-79xxE-C specified at purchase, 2x Manager Module and 4x hot swappable redundant DC-DC PSU. FG-7060E-8-DC

Артикул:

FG-7060E-8-DC

Межсетевой экран Fortinet FortiGate-7060E-8-DC 8U 6-slot chassis with 2x FPM-7620E Processor Modules, 2x FIM-79xxE-C specified at purchase, 2x Manager Module and 4x hot swappable redundant DC-DC PSU. FG-7060E-8-DC FG-7060E-8-DC #1
Межсетевой экран Fortinet FortiGate-7060E-8-DC 8U 6-slot chassis with 2x FPM-7620E Processor Modules, 2x FIM-79xxE-C specified at purchase, 2x Manager Module and 4x hot swappable redundant DC-DC PSU. FG-7060E-8-DC FG-7060E-8-DC #2
Модель: FORTIGATE 7060E / 7060EDC
Operating Temperature: 32104°F (040°C)
Storage Temperature: 31158°F (3570°C)
Model: FORTIGATE 7060E / 7060EDC
Humidity: 2090% noncondensing
Weight: 205 lbs (93 kg)
Application Control Throughput: 160 Gbps
CAPWAP Throughput: N.A
Certifications: FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
ClienttoGateway IPsec VPN Tunnels: 64,000
Concurrent SSLVPN Users (Recommended Maximum): 48,000
Concurrent Sessions (TCP): 320 Million
Firewall Policies: 200,000
GatewaytoGateway IPsec VPN Tunnels: 16,000
Height x Width x Length (mm): 352.7 x 440 x 650
High Availability Configurations: Supported
IPS Throughput (HTTP / Enterprise Mix): 360 / 120 Gbps
Maximum Number of FortiAPs (Total / Tunnel Mode): N.A
Maximum Number of FortiTokens: 5,000
Maximum Number of Registered FortiClients: 20,000
NGFW Throughput: 100 Gbps
Power Required: AC (configured with 4 PSUs in a 3+1 redundant configuration, an additional 2 PSUs can be added for additional redundancy)
SSL Inspection Throughput: 100 Gbps
SSLVPN Throughput: 15 Gbps
Threat Protection Throughput: 80 Gbps
Virtual Domains (Default / Maximum): 10 / 500
Height x Width x Length (inches): 13.4 x 17.3 x 25.6
Firewall Latency (64 byte, UDP): 7 ?s
Firewall Throughput (Packet per Second): 510 Mpps
IPsec VPN Throughput (512 byte): 100 Gbps
Firewall Throughput (1518 / 512 / 64 byte, UDP): 630 / 630 / 340 Gbps
New Sessions/Sec (TCP): 1.8 Million
DC Power Supply: 4872V DC
Fortinet Interface Module (FIM) Slots: 2
Fortinet Processor Module (FPM) Slots: 4
Heat Dissipation (Maximum): 11,184 BTU/h
Power Consumption (Maximum / Average): 3277 / 2330 W
Shelf Manager: 2
Под заказ
Цена по запросу

FG-7060E-8-DC МЕЖСЕТЕВЫЕ ЭКРАНЫ

Model FORTIGATE 7060E / 7060E-DC
Hardware Specifications
Fortinet Processor Module (FPM) Slots
 4
Fortinet Interface Module (FIM) Slots
 2
Shelf Manager
 2
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte, UDP)
 630 / 630 / 340 Gbps
Firewall Latency (64 byte, UDP)
 7 ?s
Firewall Throughput (Packet per Second)
 510 Mpps
Concurrent Sessions (TCP)
 320 Million
New Sessions/Sec (TCP)
 1.8 Million
Firewall Policies
 200,000
IPsec VPN Throughput (512 byte)
 100 Gbps
Gateway-to-Gateway IPsec VPN Tunnels
 16,000
Client-to-Gateway IPsec VPN Tunnels
 64,000
SSL-VPN Throughput
 15 Gbps
Concurrent SSL-VPN Users (Recommended Maximum)
 48,000
IPS Throughput (HTTP / Enterprise Mix)
 360 / 120 Gbps
SSL Inspection Throughput
 100 Gbps
Application Control Throughput
 160 Gbps
NGFW Throughput
 100 Gbps
Threat Protection Throughput
 80 Gbps
CAPWAP Throughput
 N.A
Virtual Domains (Default / Maximum)
 10 / 500
Maximum Number of FortiAPs (Total / Tunnel Mode)
 N.A
Maximum Number of FortiTokens
 5,000
Maximum Number of Registered FortiClients
 20,000
High Availability Configurations
 Supported
Dimensions
Height x Width x Length (inches)
 13.4 x 17.3 x 25.6
Height x Width x Length (mm)
 352.7 x 440 x 650
Weight
 205 lbs (93 kg)
Power and Environment
Power Required
 AC (configured with 4 PSUs in a 3+1 redundant configuration, an additional 2 PSUs can be added for additional redundancy)
Power Consumption (Maximum / Average)
 3277 / 2330 W
DC Power Supply
 48–72V DC
Heat Dissipation (Maximum)
 11,184 BTU/h
Operating Temperature
 32–104°F (0–40°C)
Storage Temperature
 -31–158°F (-35–70°C)
Humidity
 20–90% non-condensing
Compliance
Certifications
 FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
